Meet the Rogue R. Engineered for the ultimate MX enduro experience. Featuring custom-tuned FOX suspension, SRAM AXS GX Eagle 10-52T drivetrain, and powerful Maven Silver four-piston brakes, this bike is built to perform. Weighing just 23.6 kg and powered by an 800 Wh battery, the Rogue R delivers all-day capability with i-track enhanced suspension for unmatched control and responsiveness on any terrain. This is the ultimate DJI-powered enduro EMTB!
Size: Small, Medium, Large, Xtra Large
- Carbon fibre enduro frame,
-165mm rear travel, up to 170mm with 27.5 rear wheel
– mid-pivot
– battery integrated
– rear wheel flip chip
– shock position flip chip
– inner cable routing
– Boost 12x148mm
-16T idler, with oversize bearings. - Headset: FSA No.57 Alloy MTB ZS44/56
- Saddle: Fizik Terra Aidon X5
- Seat post lever: ONEUP Dropper lever V3.1
- Seat Post Clamp:ONEUP KIT 22.2
- Dropper:ONEUP V3 mechanical Dia.31.6
S: 180mm travel, M/L: 210mm travel,
XL: 240mm travel - Handlebar: OneUp, alloy, 800L, 35R.
- Stem: ONEUP Stem 42mm forged
- Grips: Velduro: thick grips – Black.
- Brakes:Sram Mavan Silver 4- Pistion hydraulic brake
- Discs: Sram HS2 disc front 220 , rear 200mm
- Pedal: Riders Choice
- Shift lever: Sram AXS pod controller
- Rear Derailleur: Sram AXS GX eagle transmission derailleur w/ power cable
- Crankset: Avinox SL crank 155mm
- Cassette: Sram XS-1275 10-52T
- Chain :Sram GX Flat top Chain
- Chainwheel Sram EMTB Eagle 34T
- Wheel set: Velduro e-Enduro carbon, EC-30
- Front Hub: Alloy, 2 sealed cartridge bearings, 15×110 thru-axle, 28h,
straight-pull, 6-bolt - Rear Hub: Alloy, 4 sealed cartridge bearings, 148×12 thru-axle, 28h,
straight-pull, 6-bolt, 78T - Spokes: Sapim e-light straight pull
- Rim: Carbon,F 29’/R 27.5’, 30mm internal width
- Front tire: Maxxis Assegai M356Ru 29*2.5 3C Grip/DD/TR BK
- Rear tire: Maxxis Minion DHR2 M327 Ru27.5*2.4 3C Terra/DD/TR BK
- Your Rogue is tubeless ready, but comes with tube.
- Motor: AVINOX M1 105 Nm 850W
- Battery: 800 WH
- Charger: AVINOX M1 36V 4A
- Display: AVINOX M1 DP100
- Fox 38 F-S 2026, 29 inch, 170mm,
Grip X2, 15X110mm - Fox float X2 F-S 2026, 205X65mm (custom factory tuned for the Rogue)
| S | M | L | XL | ||
|---|---|---|---|---|---|
| A | Eff. Seattube Length (mm) | 390 | 410 | 430 | 465 |
| B | Headtube Angle (°) | 63.5 | 63.5 | 63.5 | 63.5 |
| C | Eff. Toptube Length (mm) | 573.6 | 599.6 | 623.9 | 652 |
| D | Reach (mm) | 440 | 466 | 485 | 515 |
| E | Act. Seattube Angle (°) | 75.5 | 75.5 | 75.5 | 75.5 |
| F | Seattube Offset (mm) | 30 | 30 | 30 | 30 |
| G | Eff. Seattube Angle (°) | 78.1 | 78.1 | 78 | 77.9 |
| H | Chainstay Length (mm) | 440 | 440 | 440 | 440 |
| I | BB Drop at Rear Wheel (mm) | 12 | 12 | 12 | 12 |
| J | BB Drop at Front Wheel (mm) | 31 | 31 | 31 | 31 |
| K | Headtube Length (mm) | 110 | 110 | 120 | 125 |
| L | Axle to Crown (mm) | 584 | 584 | 584 | 584 |
| M | Fork Offset (mm) | 44 | 44 | 44 | 44 |
| N | Trail (mm) | 140.1 | 140.1 | 140.1 | 140.1 |
| O | Stack (mm) | 632.5 | 632.5 | 641.4 | 645.9 |
| P | Wheelbase (mm) | 1230 | 1265 | 1300 | 1335 |
| Recommended Height (CM) | 160-172 | 172-182 | 180-188 | 185-195 | |
